FixturLaser ECO Shaft Alignment System

Description

FixturLaser ECO Shaft Alignment System is an entry-level system dedicated to horizontal shaft alignment. FixturLaser ECO Shaft Alignment System with wireless sensor units, a 4” color display, rechargeable batteries, and an IP65 design that withstands harsh environments, you have a laser alignment system at an affordable price.

FixturLaser ECO Shaft Alignment System adaptive user interface will guide you throughout the measurement and alignment process. FixturLaser ECO Shaft Alignment System are especially proud of the function – VertiZontal Moves – where you only have to measure once before making the required vertical and horizontal adjustments. FixturLaser ECO Shaft Alignment System VertiZontal Moves is an innovative and time-saving feature.

FixturLaser ECO Shaft Alignment System Features:

• Wireless Convenience: Integrated Bluetooth™ ensures seamless, cable-free operation.
• High Precision: Dual inclinometers and 20mm CCD detectors handle up to 3 meters of misalignment with unmatched accuracy.
• Effortless Adjustments: The VertiZontal™ function automatically calculates shim adjustments for perfect alignment.
• Rugged Durability: Built with IP65-rated protection for harsh environments and backed by a lifetime warranty.
• User-Friendly: GuideU™ interface simplifies the alignment process with intuitive, visual instructions.

FixturLaser ECO Shaft Alignment System Included:

• 1 pce DU ECO
• 1 pce M6 sensor
• 1 pce S6 sensor
• 2 pcs V-bracket complete with chain
• 1 pce Tape measure 5 m
• 1 pce Power Supply 4 USB-port 5 VDC
• 2 pcs Universal tool
• 3 pcs USB-cable A-mini B 2 m
• 1 pce Waterproof case
• 1 pce Quick-Guide

You may also be interested in FARO Vantage Laser Tracker

FixturLaser ECO Shaft Alignment System Specifications:

FIXTURLASER ECO
Weight including all standard parts	4,8 kg (10,6 lbs) (Incl. case, excl. carton box.)
Storage temp	-20 to 70°C
Long term storage temp	Room temp. 18 to 28°C (64 to 82°F)
Case
Material	High Impact ABS Plastic
Weight (empty)	2,5 kg (5,5 lbs)
Environmental protection	Dust-, water- (5m), and airtight with air pressure compensation valve
Drop-test (empty)	3 m onto concrete floor
Storage Temp(empty)	-40 to +80 °C  (-40 to 176°F)
Dimension	415 mm x 325 mm x 180mm (16” x 13” x x 7”)
Display Unit
Housing Material	ABS plastic
Operating Temp	0 to 50°C
Storage Temp	-20 to 70°C
Long term storage temp	Room temp. 18 to 28°C (64 to 82°F)
Relative humidity	10 – 90%
Weight	346 g
Dimensions	180,9 x 105,7 x 33,9 mm (7,1” x 4,2” x 1,3”)
Environmental protection	IP 65
Flash storage memory	500 Mb
Display	Color TFT-LCD backlit
Display size	4” (102 mm) diagonal (84 x 56 mm)
Display resolution	400 x 272 pixels
Color depth	16 000 000 colors
Interface	Membrane Switch Keyboard
Peripherals	1 USB micro port (IP 67)
Wireless communication	Bluetooth (2,4 GHz)
Power supply	Rechargeable Li-Ion battery or external power supply
Operating time	8 hours continuous use
Battery Charging time (system off, room temperature)	8 h
Battery Charging Temp	0 to 40°C
Digital Laser Sensors
Housing Material	Anodized Aluminum frame and ABS plastic over-molded with TPE rubber
Operating Temp	0 to 50°C  (32 to 122°F)
Storage Temp	-20 to 70°C (-4 to 158°F)
Long term storage temp	Room temp. 18 to 28°C  (64 to 82°F)
Battery Charging Temp	0 to 40°C   (32 to 104°F)
Relative humidity	10 – 90%
Weight	M: 200 g (7,1 oz) with battery S: 188 g (6,6 oz) with battery
Dimensions	86 mm x 77 mm x 33 mm (3,4” x 3,0” x x 1,3”)
Environmental protection	IP 65
Laser	650 nm class II diode laser
Laser power	< 1 mW
Measurement distance	Up to 3 m
Detector	Digital line sensor
Detector active length	20 mm
Displayed resolution	0,01 mm
Measurement accuracy	1% ± 1 digit
Inclinometer resolution	1°
Inclinometer accuracy	±3°
Wireless communication	Bluetooth (2,4 GHz)
Communication range	10 m (33 ft)
Peripherals	1 USB Mini port (IP 67) Charging: 5V, 0,5A
Power supply	Li-Ion battery or external power.
Operating time:	12 hours continuous use (measuring)
Battery Charging time (system off, room temperature)	8 h
LED indicators	Wireless communication, laser transmission, and battery status indicators
Laser safety*
Shaft brackets
Fixture	V-fixture with non-twisting chain, width 20 mm (0,79”)
Material	Anodized aluminum
Shaft diameter	Ø 25-175 mm (1”-6.9”) Ø 25-450 mm (1”-18”) (with extension chains – optional)
Rods:	4 pcs 150 mm (5,9”) optional
Accessories
Tape measure	5 m / 16 ft metric/imperial scale
