Proceq UT8000 Ultrasonic Flaw Detector

Description

Proceq UT8000 Ultrasonic Flaw Detector represents a breakthrough in inspections with ultrasonic testing for detecting flaws such as cracks and voids in metals and composites. The Swiss Made, rugged, IP67-rated base unit is built for extreme levels of portability and comfort, from the benchtop of your lab to rope inspections in the toughest of places. Thanks to its sophisticated electronics that deliver cutting-edge bandwidth and signal-to-noise ratio, you can keep your probes and procedures.

Connect the powerful base unit to your iPad* and get to the real work faster. Our Proceq Flaw Detector Live app enhances your productivity with intelligent software features, such as the straightforward, gesture-driven calibration procedure, the built-in indication table, and the ability to rewind time for each indication. Review your measurements and communicate findings and insights enriched with voice, photo, and text annotations that deliver end-to-end traceability and peace of mind.

Proceq UT8000 Ultrasonic Flaw Detector Features:

• Unmatched performance and design with simplicity to maximize your inspection capabilities
• Ultrasonic inspection of welds, cast & forged metals, as well as composites
• Data rewind & log mapping with easy collaboration via common meeting software
• Thickness measurement, lamination assessments & more
• Deliver user friendly and fully traceable inspection data and rapid report creation.
• Capable of delivering accurate measurements at High Temperatures

Included:

• Proceq UT8000 Ultrasonic Flaw Detector with Accessories

You may also be interested in GE Inspection Technologies Autosigma 3000 Conductivity Meter

Specifications:

• Automated calibration : Velocity, zero offset
• Test modes : Pulse echo, dual, through transmission or grid
• Units : Millimeters, inches, or microseconds
• Configuration : 1 UT channel
• Transducer Socket : Lemo 00
• Pulse Voltage : 100 to 400 V (square pulse)
• PRF : 10 – 2000 Hz
• Gain Range : 0-110 dB
• Bandwidth : 0.2 – 20MHz
