Name: Leica TS13 Robotic Total Station
Brand: Leica
SKU: LTS13RTS
Availability: InStock

Leica TS13 Robotic Total Station

~~$12,200.00~~ $6,100.00

In Stock

Manufacturer: Leica
Model: TS13 Robotic Total Station
Included: Leica TS13 1” (0.3mgon) R1000 Total Station with Automatic Target Recognition, Reflectorless R1000 EDM, Electronic guide light EGL, WLAN, Bluetooth, RS232 interface, SpeedSearch, RadioHandle interface., USB stick/SD card interface, 2GB eMMC Flash Memory, 1GB SDRAM, Laser plummet, 4 button keyboard, Quick guide, Container, 1-year TS13 + CS20 Basic CCP, Tripods, Tribrachs, Reflectors, Batteries & Chargers, Data Transfer Cables, Bags & Containers

In Stock

Description

Leica TS13 Robotic Total Station is a mid-range robotic total station. It is a scalable robotic total station, powered by Leica Captivate field software and can be connected to a Leica CS20 field controller. Leica TS13 Robotic Total Station It can be upgraded at any time to benefit from additional functionalities.

Leica TS13 Robotic Total Station provides a fast, reliable, and efficient solution tailored to the users needs to measure and layout more points. Equipped with Automatic Target Recognition (ATR) technology and optionally with target lock and SpeedSearch to find and lock on to prisms quickly, it provides accurate measuring to targets. Combined with Leica Captivate field software, the Leica TS13 Robotic Total Station offers a simple and productive way of coding and line work.

Leica TS13 Robotic Total Station works with the revolutionary Leica Captivate field software, turning complex data into the most realistic and workable 3D models.

Leica TS13 Robotic Total Station Features:

Angular Measurement : 1″/2″/3″/5″
Range Non-prism : >500m (EDM R500) / >1000m (EDM R1000)
Accuracy / Measurement time : 1mm + 1.5ppm
Automatic Aiming: ATR
Motorisation : Mecanical
Internal memory: 2GB
Protection: IP55
Working temperature range : -20°C @ +50°C
Power: Li-Ion battery

Leica TS13 Robotic Total Station Included:

Leica TS13 1” (0.3mgon) R1000 Total Station with Automatic Target Recognition, Reflectorless R1000 EDM, Electronic guide light EGL, WLAN, Bluetooth, RS232 interface, SpeedSearch, RadioHandle interface.
USB stick/SD card interface, 2GB eMMC Flash Memory, 1GB SDRAM
Laser plummet
4 button keyboard
Quick guide
Container
1-year TS13 + CS20 Basic CCP
Tripods
Tribrachs
Reflectors
Batteries & Chargers
Data Transfer Cables
Bags & Containers

You may also be interested in Leica TS12P Robotic Total Station

Leica TS13 Robotic Total Station Specifications:

Angular Measurement
Accuracy 1 Hz and V	Absolute, continuous, diametrical	1” (0.3 mgon), 2” (0.6 mgon), 3” (1 mgon), 5” (1.5 mgon)
Distance Measurement
Range 2	Prism (GPR1, GPH1P) 3 Non-Prism / Any surface 4	1.5 m to 3500 m R500: 1.5 m to >500 m, R1000: 1.5 m to >1000 m
Accuracy / Measurement time	Single (prism) 2,5 Single (any surface) 2,4,5,6	1 mm + 1.5 ppm / Typically 2.4 s 2 mm + 2 ppm / Typically 3 s
Laser dot size	At 50 m	8 mm x 20 mm
Measurement technology	System analyser	Coaxial, visible red laser
Automatic Aiming- ATR Automatic
Target aiming range2	Circular prism (GPR1, GPH1P) 360° prism (GRZ4, GRZ122)	1000 m 800 m
Accuracy 1,2 / Measurement time	ATR angle accuracy Hz, V	1” (0.3 mgon), 2” (0.6 mgon), 3” (1 mgon), 5” (1.5 mgon) / Typically 3-4 s
Guide Liht (EGL)
Working range / Accuracy		5 – 150 m / Typically 5 cm @ 100 m
General
Processor	TI OMAP4430 1GHz Dual-core ARM® Cortex™ A9 MPCore™	Operating system – Windows® EC7
Power management	Exchangeable Lithium-Ion battery	Operating time 8 – 10 h
Field software	Leica Captivate incl. apps	Running on field controller (Leica CS20)
Data storage	Internal memory 2 GB SD card 1 GB or 8 GB	On field controller (Leica CS20)
Interfaces	RS232, USB, Bluetooth®, WLAN
Weight	Total station including battery	5.0 kg
Environmental specifications	Working temperature range Dust / Water (IEC 60529) / Humidity	–20°C to +50°C IP55 / 95%, non-condensing
Keyboard	Face I standard	4 button keyboard with status LEDs
Upgrades	Keboard Display Unit (Optional)
	Keyboard with display	Face I and face II optional	5” (inch), WVGA, colour, touch 25 keys, illumination
	Power management	Exchangeable Lithium-Ion battery	Operating time 6 – 8 h
	Field software	Leica Captivate including apps	Running on TS13 instrument
	Data storage	Internal memory 2 GB SD card 1 GB or 8 GB	On TS13 instrument
	Weight	Total station including battery	5.3 kg
	Target Lock (Optional)
	Target locking range2	Circular prism (GPR1, GPH1P) 360° prism (GRZ4, GRZ122)	800 m 600 m
	Robotic Surveying including Prism Fast Search (Optional)
	SpeedSearch range / Search time	360° prism (GRZ4, GRZ122)	300 m / Typically 7 s
	Robotic range with long-range Bluetooth® 8	To CS20 internal long-range Bluetooth® To CTR20 expansion pack	500 m 1000 m
