Easy Laser E710 Shaft Alignment System

~~$5,800.00~~ $2,900.00

In Stock

Manufacturer: Easy Laser
Model: E710 Shaft Alignment System
Included: E51 display unit, ES and EM measuring units, 2x Wireless modules, 2x 2 Meter cables, 4x 120mm rods, 2x Shaft brackets with chains, 2x Extension chains, 4x 60mm rods, 2x Magnetic bases, 2x Offset bracket, Manual, Quick Manual, Measuring Tape, USB memory stick with documentation, USB cable, Battery charger, 2x Toolbox, Shoulder strap for display unit, Cleaning cloth, Carrying case

In Stock

SKU: ELE710SAS

Category: Shaft Alignment System

Tag: Easy Laser E710 Shaft Alignment System

Brand: Easy Laser

Description

Easy Laser E710 Shaft Alignment System is the top of the line Easy-Laser E-series system. This is a very powerful dual dot laser system that can be cabled to the sensors or can be used wireless to do horizontal, vertical, soft foot, cardan shafts and with the E180 or XT190 belt tool will do belt alignments with live moves, documentation, reports, tolerances, etc..

Easy Laser E710 Shaft Alignment System can also take vibration data with an E285 vibration probe. Easy Laser E710 Shaft Alignment System also has geometric measurement capabilities and includes the programs for straightness, roundness, flatness, parallelism and twist. Adding the D22 we have for sale on this site makes this an E720.

Easy Laser E710 Shaft Alignment System Features:

Horizontal Machine Alignment
Vertical or Flange Mounted Machine Alignment
Cardan/Offset Mounted Machine Alignment
Multiple Machine Train Alignment
Soft Foot Check
Easy Turn Function (align with as little as 40 degrees of rotation)
Thermal Growth Compensation
Tolerance Check
Live Angle 360 (real time machine indication as you make adjusments)
Reference foot locking
Multiple Sets of Feat
Quality Assesment
Measurement Value Filter
Swap View Function

Easy Laser E710 Shaft Alignment System Included:

E51 display unit
ES and EM measuring units
2x Wireless modules
2x 2 Meter cables
4x 120mm rods
2x Shaft brackets with chains
2x Extension chains
4x 60mm rods
2x Magnetic bases
2x Offset bracket
Manual
Quick Manual
Measuring Tape
USB memory stick with documentation
USB cable
Battery charger
2x Toolbox
Shoulder strap for display unit
Cleaning cloth
Carrying case

You may also be interested in Easy Laser E420 Shaft Aligment System

Specifications:

Display Unit
Name	E51
Type of display/size	VGA 5.7” colour screen, backlit LED
Displayed resolution	0.001 mm / 0.05 thou
Power management	Endurio™ system for unbroken power supply
Internal battery (fixed)	Heavy duty Li Ion chargeable
Battery compartment	For 4 x R14 (C)
Connections	USB A, USB B, Easy-Laser® units, Charger
Operating temperature	-10–50 °C
Communication	BT wireless technology
Internal memory	>100 000 measurements can be saved
Help functions	Calculator, Unit converter
Environmental protection	IP class 65
Housing material	PC/ABS + TPE
Easy-Laser E710 Dimensions	WxHxD: 250x175x63 mm [9.8”x6.9”x2.5”]
Weight (without batteries)	1080 g [2.4 lbs]

Measuring Units
Name	EM / ES
Communication	Wireless unit 12-0436 (separate item)
Cable connection	Easy-Laser® “red cable”
Type of detector	2-axis PSD 20×20 mm [0.78″ sq]
Easy-Laser E710 Resolution	0.001 mm [0.05 mils]
Measurement accuracy	±1µm ±1%
Measurement range	Up to 20 m [66′]
Type of laser	Diode laser
Laser wavelength	635–670 nm
Laser class	Safety class 2
Laser output	<1 mW
Electronic inclinometer	0.1° resolution
Thermal sensors	± 1° C accuracy
Environmental protection	IP class 66 and 67
Temparature Range	-10–50 °C
Internal battery	Li Po
Housing material	Anodized aluminium/ABS plastics
Dimensions	WxHxD: 60x60x42 mm [2.36×2.36×1.65″]
Weight	202 g [7.1 oz]
