Name: FARO Focus X 330 HDR Laser Scanner
Brand: FARO
SKU: FFX330HDRLS
Availability: InStock

FARO Focus X 330 HDR Laser Scanner

~~$12,800.00~~ $6,400.00

In Stock

Manufacturer: FARO
Model: Focus X 330 HDR Laser Scanner
Included: Faro Focus3D X330 3D Laser Scanner [BC# -L/T*], AC Adapter, Battery, Battery Charger, Power Cord, User Manual On CD, Carrying Case [G]

In Stock

Description

FARO Focus X 330 HDR Laser Scanner Building on the success of the Focus3D, the new Focus3D X 330 surpasses previous models in functionality and performance. With a range almost three times greater than previous models, the Focus3D X 330 can scan objects up to 330 meters away and in direct sunlight. With its integrated GPS receiver, the laser scanner is able to correlate individual scans in post-processing making it ideal for surveying based applications.

FARO Focus X 330 HDR Laser Scanner quality has been increased and noise has been reduced, providing precise three dimensional models in a photo-realistic style. These advances in performance did not come at the expense of safety as the Focus3D X 330 includes a Class 1 “eye safe” laser.

FARO Focus X 330 HDR Laser Scanner data can easily be imported into all commonly used software solutions for accident reconstruction, architecture, civil engineering, construction, forensics, industrial manufacturing and land surveying.

FARO Focus X 330 HDR Laser Scanner Features:

Scanning in rough environments while providing protection from dust, debris and water splashes
Confdent data quality through the on-site compensation
Reality-like scan data by increased distance accuracy and angular accuracy
Future-proof investment and expandability due to the integrated accessory bay
Easy handling of scanner control through its large and luminous touchscreen

FARO Focus X 330 HDR Laser Scanner Included:

Faro Focus3D X330 3D Laser Scanner [BC# -L/T*]
AC Adapter
Battery
Battery Charger
Power Cord
User Manual On CD
Carrying Case [G]

You may also be interested in Faro Focus X 130

Specifications:

Ranging unit
Unambiguity interval:	By 122 till 488 Kpts/sec at 614m; by 976 Kpts/sec at 307m
Range Focus3D X 330:	0,6m – 330m indoor or outdoor with upright incidence to a 90% reflective surface
Measurement speed (pts/sec):	122,000 / 244,000 / 488,000 / 976,000
Ranging error	±2mm
Ranging noise @ 90% refl. @ 10% refl.	@10m @10m – noise compressed @25m @25m – noise compressed 0.3mm 0.15mm 0.3mm 0.15mm 0.4mm 0.2mm 0.5mm 0.25mm
Colour unit
Resolution:	Up to 70 megapixel colour
Dynamic colour feature:	Automatic adaption of brightness
Parallax:	Co-axial design
Deflection unit
Field of view (vertical/horizontal):	300° / 360°
Step size (vertical/horizontal):	0,009° (40,960 3D-Pixel on 360°) / 0,009° (40,960 3D-Pixel on 360°)
Max. vertical scan speed:	5,820rpm or 97Hz
Laser (optical transmitter)
Laser class:	Laser class 1
Wavelength:	1550nm
Beam divergence:	Typical 0,19mrad (0,011°) (1/e, halfangle)
Beam diameter at exit:	Typical 2,25mm (1/e)
Data handling and control
Data storage:	SD, SDHC™, SDXC™; 32GB card included
Scanner control:	Via touchscreen display and WLAN
New WLAN access:	Remote control, scan visualisation are possible on mobile devices with Flash®
Multi-Sensor
Dual axis compensator:	Levels each scan: Accuracy 0,015°; Range ± 5
Height sensor:	Via an electronic barometer the height relative to a fixed point can be detected and added to a scan.
Compass:	The electronic compass gives the scan an orientation. A calibration feature is included.
GPS:	Integrated GPS receiver
General
Power supply voltage:	19V (external supply) 14.4V (internal battery)
Power consumption:	40W and 80W (while battery charges)
Battery life:	4.5 hours
Ambient temperature:	5° – 40°C
Humidity:	Non-condensing
Cable connector:	Located in scanner mount
Weight:	5.2kg
Size:	240 x 200 x 100mm
Maintenance / calibration:	Annual
