Name: Trimble S7 Robotic Total Station With TSC3 Controller
Brand: Trimble
SKU: TS7RTSWTSC3C
Availability: InStock

Trimble S7 Robotic Total Station With TSC3 Controller

~~$9,800.00~~ $4,900.00

In Stock

Manufacturer: Trimble
Model: S7 Robotic Total Station With TSC3 Controller
Included: Trimble S7, hard carrying case, (2) batteries, plastic cover, Trimble TSC3 Controller with battery.

In Stock

Description

Trimble S7 Robotic Total Station With TSC3 Controller combines scanning, imaging and surveying into one powerful solution. The Trimble S7 is the system for efficient surveying, allowing you to adapt to any situation and increasing your productivity in the field.

Trimble S7 Robotic Total Station With TSC3 Controller combination of SureScan, Trimble VISION™, FineLock™ and DR Plus technology, along with many other features, means you’ll be able to collect data faster and more accurately than ever before.

Trimble S7 Robotic Total Station With TSC3 Controller is a powerful total station with all of the features and tools you need to maximize efficiency in the field and in the office.

Trimble S7 Robotic Total Station With TSC3 Controller features:

MagDrive, for exceptional speed and accuracy, reduce wear and tear, and smooth, silent operation
FineLock, which detects targets without interference from surrounding prisms, ensuring target lock over long distances, and eliminating errors caused by interference
SurePoint, ensures precise pointing and measuring by staying on target through virtually any situation, from windy weather to vibrations
Optional Trimble Sentinel tracking technology
Industry-leading field and office software for fast data collection and processing no matter the Trimble instrument

Included:

Trimble S7
hard carrying case
(2) batteries
plastic cover
Trimble TSC3 Controller with battery.

You may also be interested in Trimble S5 Robotic Total Station With TSC3 Controller

Specifications:

Leveling
Circular level in tribrach	8’/2 mm (8’/0.007 ft)
Electronic 2-axis level in the LC-display with a resolution of	0.3″ (0.1 mgon)
Laser class
EDM	Laser class 1
Laser pointer coaxial (standard)	Class 2
Overall product laser class	Laser class 2
Servo system
MagDrive servo technology	Integrated servo/angle sensor electromagnetic direct drive
Rotation speed	115 degrees/sec (128 gon/sec)
Rotation time Face 1 to Face 2	2.6 sec
Positioning speed 180 degrees (200 gon)	2.6 sec
Clamps and slow motions	Servo-driven, endless fine adjustment
Centering
Centering system	Trimble 3-pin
Optical plummet	Built-in optical plummet
Magnification focusing distance	2.3×/0.5 m to infinity (1.6 ft to infinity)
Telescope
Magnification	30×
Aperture	40 mm (1.57 in)
Field of view at 100 m (328 ft)	2.6 m at 100 m (8.5 ft at 328 ft)
Focusing distance	1.5 m (4.92 ft) to infinity
Illuminated crosshair	Variable (10 steps)
Autofocus	Standard
Camera
Chip	Color Digital Image Sensor
Resolution	2048 x 1536 pixels
Focal length	23 mm (0.09 ft)
Depth of field	3 m to infinity (9.84 ft to infinity)
Field of view	16.5° x 12.3° (18.3 gon x 13.7 gon)
Digital zoom	4-step (1x, 2x, 4x, 8x)
Exposure	Spot, HDR, Automatic
Brightness	User-definable
Image storage	Up to 2048 x 1536 pixels
File format	JPEG
Compression ratio	User-definable
Video streaming	5 frames/sec
Power supply
Rechargeable Li-Ion battery	10.8 V, 6.5 Ah
Operating time
One internal battery	Up to 6.5 hours
Three batteries in multi-battery adapter and one internal	Up to 26 hours
Weight and dimensions
Instrument (Autolock)	5.4 kg (11.35 lb)
Instrument (Robotic)	5.5 kg (11.57 lb)
Trimble TCU5 controller	0.44 kg (0.97 lb)
Tribrachx	0.7 kg (1.54 lb)
Internal battery	0.35 kg (0.77 lb)
Trunnion axis height	196 mm (7.71 in)
