Sokkia IX 503 Robotic Total Station

~~$13,400.00~~ $6,700.00

In Stock

Manufacturer: Sokkia
Model: IX 503 Robotic Total Station
Included: (1) Sokkia iX-500 Series Robotic Total Station, (2) Battery BDC70 , (2) Adjusting pin, (2) Carrying strap, (1) Charger CDC68 , (1) Power cable, (1)Stylus pen, (1) Lens cap, (1) Lens hood, (1) Tool pouch, (1) Screwdriver, (1) Lens brush, (1) Hexagon wrench, (1) Silicon cloth, (1) Startup guide, (1) USB flash drive, (1) Serial card, (1) Laser caution sign-board, (1) Carrying case, (1) Export restrictions card, (1) Registration manual, (1) Registration card, (1) Certification card, (1) Encryption card, (1) User manual

In Stock

Description

Sokkia IX 503 Robotic Total Station is an efficient single-operator robotic system with the power of long-range reflectorless measurements. Sokkia IX 503 Robotic Total Station can measure distances of up to 13,123 feet (4,000m) when using a prism and up to 1,968 feet (600m) in reflectorless mode.

Sokkia IX 503 Robotic Total Station with a rotation speed of 85 degrees per second, this robotic total station provides high- performance solution allowing construction professionals the smoothest and most accurate prism-tracking possible.

Sokkia IX 503 delivers the confidence you need without losing line-of-sight in all prism conditions. Featuring a remarkably slimmed down design, the compact system is a third smaller and lighter than previous robotic instruments, yet twice as fast. Additionally, it has customizable reporting features with intuitive processing within Magnet Office Tools.

Sokkia IX 503 Robotic Total Station Features:

(1) Reflectorless
(1) Range up to 1,968 feet
(1) Optional, pre-installed remote control handle
(1) Integrated Bluetooth
(1) Rotation speed of 85 degrees per second
(1) Advanced angle accuracy
(1) Excellent instrument algorithms
(1) Customizable reporting features within Magnet Office Tools
(1) User-friendly interface
(1) Large and bright color touchscreen
(1) Water resistant and dustproof to IP65

Included:

(1) Sokkia iX-500 Series Robotic Total Station
(2) Battery BDC70
(2) Adjusting pin
(2) Carrying strap
(1) Charger CDC68
(1) Power cable
(1)Stylus pen
(1) Lens cap
(1) Lens hood
(1) Tool pouch
(1) Screwdriver
(1) Lens brush
(1) Hexagon wrench
(1) Silicon cloth
(1) Startup guide
(1) USB flash drive
(1) Serial card
(1) Laser caution sign-board
(1) Carrying case
(1) Export restrictions card
(1) Registration manual
(1) Registration card
(1) Certification card
(1) Encryption card
(1) User manual

You may also be interested in Sokkia IM 105 Total Station

Specifications:

Weight	10.58 lbs (4.8 kg)
Warranty	5-year
Protection Class	IP65 (dust proof and water jets resistant)
Angle Measurement
Accuracy	Choice of 2-second, 3-second or 5-second
Distance Measurement
Unit of Measure (distance display)	Selectable: m/ft/in.
EDM Accuracy (Precision)	±2mm + 2 ppm
Tilt Sensor/Compensator
Range	±6 feet
Type	Liquid 2-axis tilt sensor
Battery/Power
Power Source	Battery
Battery Life	Up to 4 hours
Battery Life Alert	Yes
Optical Plummet
Magnification	30x
Telescope
Magnification	30x
Reflectorless	Yes
Display and Keypad
Type	Color touch LCD
Keys	24 keys with illuminator
Touchscreen	Yes
Backlight	Yes
Temperature
Operating	-4Fº~122ºF (-20ºC~50ºC)
Applications
Surveying and Construction	Yes
Mapping and GIS (geographic information systems)	Yes
Utilities	Yes
Environment Studies	Yes
Geomarking	Yes
Archaeology	Yes
Accident Reconstruction	Yes
Measurement Range (under fair weather conditions)
Single Prism	13,123 ft (4,000 m)
No Prism	1,968 ft (600 m)
Functions
Coordinate Measurement Point	Yes
Angle and Distance Stake Out	Yes
Interface
Bluetooth	Yes
USB	2.0 (Host + Slave)
