Leica Viva GS25 High Precision Receiver

Description

Leica Viva GS25 High Precision Receiver high-precision receivers combine all features to provide peak performance, even under the most demanding conditions. Rest assured you are receiving the most accurate results when you count on the positioning reliability of the GS25.

Leica Viva GS25 High Precision Receiver Ensure today’s and tomorrow’s success with these outstanding GNSS receivers that offer upgrade functionality options to adapt with advancing satellite positioning systems. Regardless of the task at hand, enjoy the confidence that comes with a job well done using the Leica Viva GS25 High Precision Receiver.

Leica Viva GS25 High Precision Receiver come with the revolutionary Leica Captivate software, turning complex data into the most realistic and workable 3D models.

Leica Viva GS25 High Precision Receiver easy-to-use apps and familiar touch technology, all forms of measured and design data can be viewed in all dimensions. Captivate spans industries and applications with little more than a simple swipe, regardless of whether you work with GNSS, total stations or both.

Leica Viva GS25 High Precision Receiver Features:

• Engaging software
• Infinite possibilities
• Customer care at a click
• Powerful handheld devices

Included:

• Leica Viva GS25 High Precision Receiver
• 3.5G phone modem Radio modem
• Bluetooth
• Leica Captivate software
• Leica SmartWorx Viva software

You may also be interested in Leica Viva GS16

Specifications:

Leica GS08+	Leica GS14	Leica GS16	Leica GS18 T	Leica GS10	Leica GS25
Signal tracking	Dual-frequency	Dual-frequency	Multi-frequency	Multi-frequency	Multi-frequency	Multi-frequency
GPS GLONASS Galileo BeiDou SBAS
SmartLink fill SmartLink
Tilt compensation
Single baseline RTK	Hz 10 mm + 1 ppm / V 20 mm + 1 ppm	Hz 8 mm + 1 ppm / V 15 mm + 1 ppm	Hz 8 mm + 1 ppm / V 15 mm + 1 ppm	Hz 8 mm + 1 ppm / V 15 mm + 1 ppm	Hz 8 mm + 1 ppm / V 15 mm + 1 ppm	Hz 8 mm + 1 ppm / V 15 mm + 1 ppm
Network RTK	Hz 10 mm + 0.5 ppm / V 20 mm + 0.5 ppm	Hz 8 mm + 0.5 ppm / V 15 mm + 0.5 ppm	Hz 8 mm + 0.5 ppm / V 15 mm + 0.5 ppm	Hz 8 mm + 0.5 ppm / V 15 mm + 0.5 ppm	Hz 8 mm + 0.5 ppm / V 15 mm + 0.5 ppm	Hz 8 mm + 0.5 ppm / V 15 mm + 0.5 ppm
Static (phase) with long observations	Hz 3 mm + 0.5 ppm / V 6 mm + 0.5 ppm	Hz 3 mm + 0.1 ppm / V 3.5 mm + 0.4 ppm	Hz 3 mm + 0.1 ppm / V 3.5 mm + 0.4 ppm	Hz 3 mm + 0.1 ppm / V 3.5 mm + 0.4 ppm	Hz 3 mm + 0.1 ppm / V 3.5 mm + 0.4 ppm	Hz 3 mm + 0.1 ppm / V 3.5 mm + 0.4 ppm
Static and rapid static (phase)	Hz 5 mm + 0.5 ppm / V 10 mm + 0.5 ppm	Hz 3 mm + 0.5 ppm / V 5 mm + 0.5 ppm	Hz 3 mm + 0.5 ppm / V 5 mm + 0.5 ppm	Hz 3 mm + 0.5 ppm / V 5 mm + 0.5 ppm	Hz 3 mm + 0.5 ppm / V 5 mm + 0.5 ppm	Hz 3 mm + 0.5 ppm / V 5 mm + 0.5 ppm
Reliability	99,95%	99,95%	99,95%	99,95%	99,95%	99,95%
5 Hz 20 Hz positioning
Raw data RINEX data logging NMEA out
RTK reference station functionality
Cellular / UHF Radio (receive & transmit) modem	Controller internal	3G	3G	4G	3G	3G
Storage	Controller internal	MicroSD card	MicroSD card	SD card	SD card	SD card
User interface Buttons LEDs Display	1 3	2 7	2 7	2 8	2 7	7 7
Power, Bluetooth®, USB, RS232
Event, PPS
Operating temperature -40°C to 65°C
IP68 proof against water, sand and dust
Weight (without battery)	0.60 kg	0.93 kg	0.93 kg	1.20 kg	1.20 kg	1.84 kg
